Filter Cartridges — Pleated, Depth & Membrane (MEMFLO)

The MEMFLO series covers the full spectrum of liquid and gas filtration — from coarse pre-filtration to sterilizing-grade final filtration — in a pleated cartridge format engineered for high flow, high throughput and long service life. Whatever your fluid, there's a MEMFLO media and micron rating to match.

Specifications

• Filter media: Polypropylene (PP), Polyethersulfone (PES), PTFE, Nylon and glass fibre
• Micron ratings: 0.05, 0.2, 0.45, 1, 3, 5, 10 and 15 µm
• Lengths: 1.5", 2.5", 5", 10", 20", 30" and 40"
• Diameter / area: 70 mm OD standard; ~0.62 m² effective area per 10" cartridge
• End connections: 226, 222, DOE, IOR and other industry-standard fittings
• O-rings / gaskets: Silicone, EPDM, Viton® and FEP-encapsulated (FEP/PFA)
• Sterilization: autoclave, hot-water and in-line steam (SIP/CIP capable)
• Compliance: FDA 21 CFR Title 21, USP Class VI, ISO 10993; food-contact per EC 1935/2004; manufactured in an ISO-class cleanroom
• Testing: 100% integrity-tested — bubble point (BPT), water intrusion (WIT) and diffusion/forward-flow; endotoxin per USP <665>; bacterial retention validated to ASTM F838-20

Typical applications: sterile filtration of injectables, vaccines and blood products · bioburden reduction · culture media and buffer filtration · WFI and purified-water final filtration · beverage clarification and polishing · solvent, resin, acid and alkali filtration · pre-filtration for downstream membrane

PED/EN/ISO Compliant Filter Housing

This series of high-quality filter housings for critical liquid and gas filtration is designed and built in conformance with ASME Sec VIII Div 1 & PED 2014/68/EU (Module H), delivering the highest levels of sanitary performance in the industry. Meticulous selection of materials, designs and manufacturing processes — including qualified welding procedures and surface treatments — aligns every unit with these standards, giving full confidence that the product conforms to the required safety protocols and Performance.

MEMCAP Capsule filters

Ready-to-use filtration.

MEMcap™ capsule filters are self-contained, single-use filtration devices engineered for sterilizing-grade and bioburden-reduction applications in pharmaceutical, biotechnology, and life-science manufacturing. Each capsule integrates a pleated membrane element within a robust polypropylene housing — eliminating the need for stainless steel housings, cleaning cycles, and cleaning validation.

Available in dual-layer PES, PTFE, Nylon, Glass Fibre, and PP membrane configurations across a full range of pore sizes (0.1 µm to 5 µm) and 2.5", 5", 10", 20", and 30" formats, MEMcap™ capsules deliver high flow rates, low extractables, and consistent lot-to-lot performance.

Every MEMcap™ device is 100% integrity tested, gamma-sterilizable or autoclavable, and supported by comprehensive validation documentation aligned to ASTM F838, USP <88> Class VI, USP <665>/<1665>, and PDA TR 26/40 requirements.

Applications: sterile filtration of aqueous pharmaceutical solutions, buffers, cell culture media, WFI, vaccines, biologics; vent and gas filtration; small-volume and pilot-scale bioprocessing.

Filtration you can prove.

Sintered Metal Filter Elements [MET-FLO series]

Discover the MET-FLO Series — our premium sintered metal filter elements, engineered and manufactured at our state-of-the-art facility in Indore, India. Trusted across industries for decades, these robust, high-performance filters are available in a wide range of micron ratings and custom dimensions.

Ideal for steam filtration, gasification, catalyst recovery, hydrogenation, product clarification, and fine particle removal, MET-FLO™ elements are cleanable and reusable multiple times (depending on application)—delivering superior performance with lower lifetime cost.

Partner with us for expert filter sizing, design consultation, and cost-effective filtration solutions tailored to your process needs.
